Customizable Image Settings 5MP USB Camera Module for Visual Recognition Scenarios

Name: Customizable Image Settings 5MP USB Camera Module for Visual Recognition Scenarios
Brand: Sinoseen
Price: 1 USD

Customizable Image Settings 5MP USB Camera Module for Visual Recognition Scenarios Manufactures

Brand Name : Sinoseen

Model Number : SNS-GM1133-V1.0

Certification : RoHS

Place of Origin : China

MOQ : 5

Price : negotiable

Payment Terms : T/T

Supply Ability : 500000 pieces/month

Delivery Time : 2-3week

Packaging Details : Tray+Anti-static bag in carton box

Sensor Type : CMOS

Module Size : Two Layers 38mmX38mm

Audio Input : Channel Audio MIC Input

Standard Interface : USB2.0 High Speed

Pixel Size : 1.4µm x1.4µm

Coded Format : H.265/H.264

Power Consumption : About 140mA

Object Distance : 6CM-200CM

Driving Method : Drive Free

F Number : 2.2

Operating Current : 610mA(VGA)

Max Image Circle : 4.8mm

Artwork : 8-Layer Design

Warranty : 10 Years

Compatibility : Windows, Mac, Linux

Contact Now

Sinoseen GM1133 1/2.8" vb1940 CMOS 5MP camera module with high-speed USB2.0 interface for seamless connection. This advanced digital image sensor delivers sharp images at a resolution of 2592x1944 and a frame rate of 30FPS, making it particularly suitable for machine vision applications. Support plug and play functions and a variety of operating systems, widely used in video conferencing, monitoring, industrial testing and other fields. It features enhanced low-light performance and customizable image Settings.

Upgrade your imaging solution with Sinoseen multifunctional camera modules that perfectly meet professionals' needs for superior image quality and reliability in a variety of visual recognition scenarios.

Signal		SNS-GM1133-V1.0	REMARKS
Image Sensor Size(图像感光尺寸)		1/2.8inch
Effective Pixels(有效像素)		2592H*1944V
Pixel size(像素点大小)		2.0 um*2.0 um
Optical distortion(畸变)		<0.45%
Image sensor Data output(数据输出类型)		Raw Bayer 10bits
Video output(输出格式)		MPJG/YUV
Maximum Frame Rates(分辨率和帧率)		25921944 30 FPS 19201080 30 FPS 1600*1200 30 FPS	MJPG
SNR max(信噪比)		TBD
Dynamic range(动态范围)		TBD
Min. Illumination(最低照度)		TBD
Digital interface(连接接口)		Type-c USB2.0	线长1.5米
Transfer rates(接口速度)		480MB/S
Power requirements(电源)		5V±5%
Storage temperature储藏温度		-20℃to70℃
operating temperature 工作温度		-10℃to60℃
Power Consumption (功率)	NO LED	/
	IR-LED	/
PCB printig ink		black
OS(支持系统)		Windows XP /vista/seven/8.1/10/Mac /Android/linux2.6.2(include UVC )
Lens view (默认镜头)		M12*P0.5	LENS
Lens Construction 镜头结构		3G2P+650IR
F/NO光圈		3.0±5%
EFL 有效焦距		4.18 mm±5%
FOV 角度		82°±3°
对焦方式		定焦
拍摄距离		60cm-∞

Customizable Image Settings 5MP USB Camera Module for Visual Recognition Scenarios

Customizable Image Settings 5MP USB Camera Module for Visual Recognition Scenarios Images
