Full Featured OV2735 30FPS MJPEG Low Power USB Camera Module For Dash Cams

Name: Full Featured OV2735 30FPS MJPEG Low Power USB Camera Module For Dash Cams
Brand: Sinoseen
Price: 1 USD

Full Featured OV2735 30FPS MJPEG Low Power USB Camera Module For Dash Cams Manufactures

Brand Name : Sinoseen

Model Number : SNS-WK2735-V1.0

Certification : RoHS

Place of Origin : Shenzhen,China

MOQ : 1

Price : negotiable

Payment Terms : T/T

Supply Ability : 500000 pieces/month

Delivery Time : 2-3weeks

Packaging Details : Tray+Anti-static bag in carton box

Type : USB camera module

Sensor : 1/2.7" Omnivision OV2735

Resolution : 2MP 1920x1080

Dimensions : customizable

Lens FOV : 97(optional)

Focus Type : fixed focus

Interface : USB2.0

Feature : HD

Contact Now

Full Featured HD OV2735 30 FPS MJPEG YUV Low Power USB Camera Module for driving recorder

USB Camera Module

This is a full featured HD 1080p/720p camera module with OV2735 sensor. Refers to devices that support IP cameras, HD analog cameras, or 1080p video capture at 30fps. Support low power consumption mode, maintain stable image quality in the operating temperature range of 0"C to 60%C, and significantly reduce power consumption. This module can be programmed to control: gain, exposure, frame rate, image size, horizontal mirroring, Vertical flip, crop and window.

Specification

Module No	SNS-WK2735-V1.0
Pixel Size	3.0μm x 3.0μm
Effective Pixels	1920(H)X1080(V)
Video output	YUV2 MJPG
Active Array Size Video Rate	1080p@30FPS
Image Sensor	1/2.7" OV2735
SNR max	TBDdB
Dynamic range	TBDdB
OTG	USB2.0 OTG
AEC	Support
AEB	Support
AGC	Support
Adjustable parameter	Brightness/Contrast/Color saturation/Hue/Definition/Gamma/White balance/Exposure
Lens view	FOV:D97° H83°V56°F/N(2.0)
Interface	USB BUS POWER 5P-1.25mm
Operating Voltage	DC5V
Operating Current	MAX120MMA
Operating temperature	0～60℃
Storage temperature	-20～80℃
Cable length	Defualt
OS	WinXP/Vista/Win7/Win8 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC

Full Featured OV2735 30FPS MJPEG Low Power USB Camera Module For Dash Cams

Shenzhen Sinoseen Technology Co.,Ltd

China top 10 camera module manufacturer

We customize all kinds of USB/MIPI/DVP camera module as per your request

FAQ:

Q1. How to choose the right camera module?
A: Please tell us your specific needs, such as application scenarios, resolution, size, and lens requirements. We will have a professional team of engineers to assist you in choosing the most suitable camera module.

Q2. How to start proofing?
A: After confirming all the parameters, we will draw a drawing to confirm the details with you. Once the drawing is confirmed, we will arrange a proofing.

Q3: How do I send the payment?
A: Currently we accept T/T bank transfer and Paypal.

Q4: How long does it take to make a sample?
A: If it is a USB camera module, it usually takes 2-3weeks, if it is a MIPI or DVP camera module, it usually takes 10-15days.

Q5: How long will it take to receive the sample after it is ready?
A: After the samples have been tested and there is no problem, we will send the samples to you via DHL FedEx UPS or any other courier methods, usually within a week.
