Custom 2MP HD 1920x1080P USB Camera Module With GC2053 Sensor

Name: Custom 2MP HD 1920x1080P USB Camera Module With GC2053 Sensor
Brand: Sinoseen
Price: 1 USD

Custom 2MP HD 1920x1080P USB Camera Module With GC2053 Sensor Manufactures

Brand Name : Sinoseen

Model Number : SNS-GC2053-V1.0

Certification : RoHS

Place of Origin : Shenzhen,China

MOQ : 3

Price : negotiable

Payment Terms : T/T

Supply Ability : 500000 pieces/month

Delivery Time : 2-3weeks

Packaging Details : Tray+Anti-static bag in carton box

Type : 2MP camera module

Sensor : 1/2.9’GC2053 CMOS

Resolution : 1920(H) x 1080(V)

Dimensions : (customizable)

Pixel Size : 2.8um x2.8um

Focus Type : Fixed Focus

Interface : USB2.0

Feature : HDR

Contact Now

Customized 2Mega CMOS Image Sensor HD 1920x1080P USB Camera Module with GC2053 Sensor

1080P USB Camera Module

This is a USB camera module for monitoring and identification. It adopts a non-distorted lens and is equipped with a GC2053 sensor. The GC2053 sensor is a high-quality 1080P CMOS image sensor. This camera module features fully integrated high performance and low power consumption, making it an optimal design.
 Features: Size: 1/2.7
 Maximum resolution: 1920*1080
 1. MJPEG/YUY2 dual output format optional
 2. It has the characteristics of high definition and high dynamics, and can also have good image quality output under low light conditions
 3. Complete 1080P full-frame image array, 30FPS per second, 720P resolution up to 60FPS Application: commonly used in security, driving recorder, network camera, video conference all-in-one, advertising all-in-one and other fields
 The camera module can also be used in surveillance cameras, automotive, cell phone cameras, digital cameras and video cameras, videophones and conferencing equipment.

Specification

Model No	SNS-GC2053-V1.0
Sensor	1/2.9’GC2053 CMOS
Pixel	2 Mega Pixel
Most effective pixels	1920(H) x 1080(V)
Pixel Size	2.8um x2.8um
Image Area	5808µm x 3288µm
Compression format	YUV2 / MJPG
Resolution	See above
Frame rate	See above
Shutter Type	Electronic rolling shutter
Focus type	Fixed focus
S/N ratio	TBDdB
Dynamic range	TBDdB
Sensitivity	3700 mV/lux-sec
Interface type	USB2.0
Adjustable parameter	Brightness/Contrast/Color saturation/Hue/Definition/ Gamma/White balance/Exposure
Power supply requirement	AVDD28: 2.7~3.3V(Typ.2.8V)
	DVDD18: 1.15~1.3V(Typ.1.2V)
	IOVDD: 1.7~3.0V(Typ.1.8V)
Audio frequency	Optional
Power supply	USB BUS POWER
Power consumption	DC 5V, 200mA
Main chip	DSP/SENSOR/FLASH
Auto Exposure Control (AEC)	Support
Auto White Balance (AEB)	Support
Auto Gain Control (AGC)	Support
Storage temperature	0~60℃
Operating temperature	-20~80℃
USB cable length	Default
Support OS	WinXP/Vista/Win7/Win8/Win10 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC
