OV9281 Sensor 1MP MIPI Camera Module For Industrial Testing

Name: OV9281 Sensor 1MP MIPI Camera Module For Industrial Testing
Brand: Sinoseen
Price: 1 USD

OV9281 Sensor 1MP MIPI Camera Module For Industrial Testing Manufactures

Brand Name : Sinoseen

Model Number : SNS-11558-v1.0

Certification : RoHS

Place of Origin : Shenzhen,China

MOQ : 5

Price : negotiable

Payment Terms : T/T

Supply Ability : 500000 pieces/month

Delivery Time : 2-3weeks

Packaging Details : Tray+Anti-static bag in carton box

Type : USB camera module

Sensor : 1/4" Omnivision OV9281 CMOS

Resolution : 1MP 1280(H) x 800(V)

Dimensions : customizable

Lens FOV : 60°(optional)

Focus Type : Fixed focus

Interface : MIPI

Feature : Global shutter

Contact Now

OV9281 PCB MIPI Raspberry Pi Global Exposure Camera Module for Industrial Testing

This is a dedicated camera module for Raspberry Pi. Use the OV9281 B&W sensor, a high-speed global shutter image sensor for accurate and fast capture of moving scenes at 720p resolution and 60 fps. This mod captures images at high frame rates, helping to minimize frame-to-frame distortion and reduce motion blur, while capturing fast-moving objects for smoother images and richer scene details.

And the module can bring 1-megapixel resolution to a variety of consumer and industrial computer vision applications, including augmented reality, virtual reality. Features best-in-class near-infrared quantum efficiency for high resolution and low latency requirements.

Specification

Model No	SNS-11558-v1.0
Sensor	1/4" Omnivision OV9281 CMOS
Pixel	1 Mega Pixel
Most effective pixels	1280(H) x 800(V)
Pixel Size	3.0µm x 3.0µm
Image area	3896um(H) x 2453um (V)
Compression format	MJPG / YUY2
Resolution & Frame rate	See above
Shutter Type	Global Shutter
Chroma	B&W, Monochrome
Focus type	Fixed focus
S/N ratio	38dB
Dynamic range	68dB
Dark current	80e-/sec
Interface type	High speed USB2.0
Adjustable parameter	Brightness/Contrast/Color saturation/Hue/Definition/ Gamma/White balance/Exposure
Lens	Focal length: 3.6mm
	Lens Size: 1/4 inch
	FOV: 60°
	Thread Size: M12*P0.5
Audio frequency	Optional
Power supply	USB BUS POWER
Power consumption	DC 5V, 180mW
Main chip	DSP/SENSOR/FLASH
Auto Exposure Control	Support
Auto White Balance	Support
Auto Gain Control	Support
Dimension	Customizable
Storage temperature	-20°C to 70°C
Operating temperature	0°C to 60°C
USB cable length	Default
Support OS	WinXP/Vista/Win7/Win8/Win10 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Android 4.0 or above with UVC

OV9281 Sensor 1MP MIPI Camera Module For Industrial Testing

Shenzhen Sinoseen Technology Co.,Ltd

China top 10 camera module manufacturer

We customize all kinds of USB/MIPI/DVP camera module as per your request

Current avaliable global shutter USB camera module

Omnivision OV7251 0.3MP Monochrome(black and white)

Omnivision OV9281 1MP Monochrome(black and white)

ON Semiconductor AR0144 1MP Monochrome(black and white) or RGB color

Omnivision OG02B1B 2MP Monochrome(black and white)

Omnivision OG02B10 2MP RGB color
